Generator Set Specification | ||
Model | A-C138M | |
Max. Power | kVA | 138 |
kW | 110 | |
Rate Power | kVA | 125 |
kW | 100 | |
Frequency | Hz | 50 |
Rate Voltage | V | 400/230 |
Rate Current | A | 180.4 |
Fuel Tank Capacity | L | 250 |
Dimension For Open-type Genset | mm | 2000 X 820 X 1450 |
Weight For Open-type Genset | kg | 1250 |
Dimension For Soundproof Genset | mm | 2450 X 1080 X 1500 |
Weight For Soundproof Generator | kg | 1750 |
Noise Level for Soundproof Generator at 7M | dBA | 75 |
Battery | Two of 80Amps Free Maintenance Battery |
Engine Specification | ||
Engine Manufacturer | Dongfeng Cummins Engine Co., Ltd. | |
Engine Brand | Cummins | |
Engine Model | 6CT8.3-GM115 | |
No. of Cylinder | 6 Cylinder in line | |
Aspiration | Turbocharged & Aftercooled | |
Governor | Electric | |
Engine Max. Output Power | kW | 116.6 |
Displacement | L | 5.9 |
Compression Ratio | 17.3 : 1 | |
Starting Voltage | V | 24 |
Bore | mm | 102 |
Stroke | mm | 120 |
Lubrication Oil Capacity | L | 16.4 |
Intake Air Flow | L/S | 112 |
Fuel Consumption at 100% Load | L/H | 27 |
OPTIONAL EQUIPMENT
FAQ
Q: Do you offer OEM service?
A: Yes
Q: What is your payment term?
A: 30% T/T in advance, 70% balance when receiving B/L copy, Or 100% irrevocable L/C at sight.
Q: What is your lead time?
A: About 20-30 days after receiving advance deposit or original L/C.
Q: What warranty do you provide?
A: One year, during the guarantee period, we will supply free of the easily damaged parts for the possible problems except for the incorrect operation. After expiration, we supply cost spare parts for Genset maintenance.
