High Voltage Generator Set

1. Powered by Cummins G-drive engine 6BT5.9-G2,   1) Water cooling, 4 stroke, 6 cylinders   2) Radiation with water tank & fan & safeguard 3. Alternator: Original Stamford/Marathon (Made in China) or Hosem Brushless Alternator   1) Single bearing, 4pole, and self-excited brushless.   2) Insulation --H class, Protection -- IP22 (IP23 in marine)   3) AVR(auto voltage regulation) Control System: Key starting, Auto control panel, Remote control panel, ATS(Auto transfer switch)   Cummins 100kVA Diesel Generator Specification

Model GFW11-200AB(E) GFW11-220AB(E) GFW11-250AB(E) GFW11-200AGB(E) GFW11-220AGB(E) GFW11-250AGB(E) Rated Welding Current(A) 200 220 250 200 220 250 Welding voltage(DC)(v) 24-30 24-30 24-32 24-30 24-30 24-32 Welding current range(A) 50-200 50-220 50-250 50-200 50-220 50-250 Applicable ElectrodeΦ(mm) 2.5-4.0 2.5-4.0 2.5-5.0 2.5-4.0 2.5-4.0 2.5-5.0 Duty Cycle  0.6 0.6 0.6 0.6 0.6 0.6 Phase  Single phase/Three phase AC Frequency(Hz) 50 / 60Hz 50 / 60Hz 50 / 60Hz 50 / 60Hz 50 / 60Hz 50 / 60Hz Rated AC Output (KW) 5.0/6.0 6.0/7.0 7.0/7.5 5.0/6.0 6.0/7.0 7.0/7.5 Rated AC Output Voltage(V) 110；120；110/220；120/240；220；230；240；220/380；230/400 Engine Model  GF190F(E) GF192F(E) GF192FB GF190F(E) GF192F(E) GF192FB Max. Outpput (HP) 15 17 18 15 17 18 Displacement (cc) 420 440 460 420 440 460 Type  Single-cylinder,4-stroke,Air cooled,OHV Compression ratio  8.3：1 Starting System  Recoil/Electric           Lubrication Systerm Forced Lubrication           Fuel Tank  (L) 6.5 6.5 6.5 11 11 11 Oil Capacity  (L) 1.1 1.1 1.2 1.1 1.1 1.2 Noise Level (Db/7m) 66 66 70 66 66 70 Packing Dimensions(mm) 810X545X560 810X545X560 810X545X560 810X545X560 810X545X560 810X545X560 Gross Weight(kg) 90 93 107 93 96 110

Model Standby Power  Prime Power Engine Model Dimension Open Type Weight Datasheet kVA kW kVA kW LXWXH(MM) KG A-KF22 22  18  20  16  4YT23-20D 1550x800x1350 750 Download A-KF28-1 28  22  25  20  4YT23-30D 1550x800x1350 780 Download A-KF28-2 28  22  25  20  K4100DS 1550x800x1350 780 Download A-KF28-3 28  22  25  20  N4100DS-30 1550x800x1350 780 Download A-KF33-1 33  26  30  24  N4100DS-30 1550x800x1350 800 Download A-KF33-2 33  26  30  24  K4100DS 1550x800x1350 800 Download A-KF41-1 41  33  38  30  K4100ZDS 1550x800x1350 850 Download A-KF41-2 41  33  38  30  N4105DS-38 1550x800x1350 850 Download A-KF47 47  37  43  34  K4100ZDS 1550x800x1350 880 Download A-KF55-1 55  44  50  40  N4105DS-42 1550x800x1350 950 Download A-KF55-2 55  44  50  40  N4105ZDS 1550x800x1350 950 Download A-KF55-3 55  44  50  40  R4105DS 1550x800x1350 950 Download A-KF55-4 55  44  50  40  R4105ZDS 1550x800x1350 950 Download A-KF69-1 69  55  63  50  N4105ZDS 1750x900x1350 980 Download A-KF69-2 69  55  63  50  N4105ZLD 1750x900x1350 980 Download A-KF69-3 69  55  63  50  R4105ZDS 1750x900x1350 980 Download A-KF69-4 69  55  63  50  R4105ZLDS 1750x900x1350 980 Download A-KF83-1 83  66  75  60  R4105ZLDS 1750x900x1350 1050 Download A-KF83-2 83  66  75  60  R4105BZLDS 1750x900x1350 1050 Download A-KF83-3 83  66  75  60  N4105ZLD 1750x900x1350 1050 Download A-KF88 88  70  80  64  R6105ZDS 2150x1080x1500 1050 Download A-KF103-1 103  83  94  75  R6105ZDS 2150x1080x1500 1200 Download A-KF103-2 103  83  94  75  4RT55-88D 1750x900x1350 1200 Download A-KF110 110  88  100  80  4RT55-110D 1750x900x1350 1250 Download A-KF125 125  100  113  90  R6105ZLDS 2150x1080x1500 1300 Download A-KF138-1 138  110  125  100  4RT55-110D 1750x900x1350 1380 Download A-KF138-2 138  110  125  100  R6105AZLDS 2500x980x1650 1380 Download A-KF165-1 165  132  150  120  R6105BZLDS 2500x980x1650 1400 Download A-KF165-2 165  132  150  120  6RT80-132D 2500x980x1650 1400 Download A-KF206-1 206  165  188  150  6RT80-176D 2500x980x1650 1480 Download A-KF206-2 206  165  188  150  R6110ZLDS 2500x980x1650 1480 Download A-KF220 220  176  200  160  6126-68DE 2530x980x1650 1500 Download A-KF248 248  198  225  180  6126-42DE 2530x980x1650 1560 Download A-KF275 275  220  250  200  6126A-260DE 2530x980x1650 1580 Download A-KF303 303  242  275  220  6127A-275DE 2930x1080x1650 1650 Download A-KF385-1 358  286  325  260  WT12D-308E 2930x1080x1650 2450 Download A-KF385-2 385  308  350  280  WT12D-330DE 2930x1080x1650 2450 Download A-KF385-3 385  308  350  280  WT13D-330DE 2930x1080x1650 2450 Download A-KF440 440  352  400  320  WT13-360DE 2930x1080x1650 2800 Download A-KF500 500  400  450  360  WT13A-390DE 2930x1080x1650 2800 Download

Model Standby Power  Prime Power Engine Model Dimension (Open Type) Weight Datasheet kVA kW kVA kW LXWXH(MM) KG A-YM13M - - 13 10 3TNV88-GGE 1020X570X900 480 Download A-YM15M - - 15 12 4TNV88-GGE 1180X570X910 510 Download A-YM23M - - 23 18 4TNV88-GTE 1350X570X910 550 Download A-YM31M - - 31 25 4TNV88-GLE 1470X660X1120 660 Download

This mobile light tower is powered by reliable Kubota, Yanmar, Perkins, or Quanchai water-cooled 3 or 4-cylinder diesel engines, ensuring dependable performance. Key features include: Powerful Lighting: Equipped with four 400W LED floodlights, delivering a total of 240,000 lumens to provide bright, efficient illumination across large areas. Advanced Digital Control: Features a Smartgen HGM1790N digital controller panel with pre-alarm and shutdown functions, offering alerts for low oil pressure, high temperature, engine overspeed, and generator over/under voltage or overload, ensuring reliable and safe operation. Durable and Resilient: Shock-resistant fixtures are designed to last, providing durability even in tough conditions. Weatherproof and Soundproof Design: Built for outdoor use, the light tower's enclosure offers protection against harsh weather and reduces noise, making it suitable for various environments. Enhanced Stability: Outfitted with one outrigger and four leveling jacks, ensuring stability on uneven terrain and different ground conditions. Sturdy Mechanical Mast: A robust 9-meter mechanical mast with 1,800 lbs self-locking winches provides reliable height adjustment and durability. Flexible and Efficient: Features 359° non-continuous tower rotation and a retractable mast cable, allowing easy positioning for optimal lighting coverage.

1. Powered by brand new original Cummins water-cooled diesel engine. 2. Alternator options: Brand new STAMFORD, LEROY SOMER, or Hosem single bearing 3 phase alternator with IP23 and H insulation class. 3. Copper 40ºC radiator with the engine-driven fan mounted on the skid. 4. Delixi or Chint branded case circuit breaker mounted. 5. Heavy-duty fabricated steel-based frame with built-in fuel tank for at least 8 hours of continuous running. 6. Complete set mounted on a based frame with anti-vibration mountings. 7. Industrial 9 dB muffler exhaust system with flexible connects and bellows. 8. Based frame with fuel, oil, and coolant drain cocks for easy maintenance. 9. 12/24V DC electric start system with free maintenance battery & smarten brand battery charger. 10. Set mounted automatic control panel, with SMARTGEN or Deepsea and ComAp controller module with AMF function for automatic start & stop. 11. Document supply: test report of the generator, set of drawings, and manuals.

Configuration:   Engine: Isuzu Alternator: Stamford Power Output: 20kVA, 25kVA, 30kVA, 38kVA, 50kVA.   Control Panel: Deeosea Safety Features: Low oil pressure shutdown and overload protection for enhanced safety and generator protection. Fuel Tank: 8 hours runtime. Noise Level: 70-72dB(A) @ 7 Meters

1. Powered by Cummins G-drive engine,   1) Water cooling, 4 stroke, 12 cylinders   2) Radiation with water tank & fan & safeguard 3. Alternator: Original Stamford/Marathon (Made in China) or Hosem Brushless Alternator   1) Single bearing, 4pole, and self-excited brushless.   2) Insulation --H class, Protection -- IP22 (IP23 in marine)   3) AVR(auto voltage regulation) Control System: Key starting, Auto control panel, Remote control panel, ATS(Auto transfer switch)
