Engine Model: JE493ZDB-04
Engine Type: 4-cylinder inline, four-stroke
Displacement: 2.77 liters
Bore and Stroke: 93 mm x 102 mm
Cooling System: Water-cooled
Turbocharger: Yes
Aftercooler: No
Governing System: mechanical governor
Starting System: Electric start
Alternator Type: Brushless, self-excited
Control Panel: Deepsea/ Smartgen
Voltage Regulation: Automatic voltage regulation (AVR)
Enclosure: Soundproof or weatherproof enclosure (optional)
Fuel Tank: Integrated fuel tank (optional)
Item no.:
A-I33Payment:
TT/LCProduct origin:
ChinaLead Time:
30-35 days
Introducing Generator with Isuzu JE493ZDB-04 Engine:
Our generator powered by the Isuzu JE493ZDB-04 engine combines robust performance, durability, and fuel efficiency to meet your power needs. The Isuzu JE493ZDB-04 engine is a reliable and trusted power source known for its exceptional performance in various applications.
Key Features:
Isuzu JE493ZDB-04 Engine: The heart of our generator, the Isuzu JE493ZDB-04 engine, is renowned for its durability, reliability, and fuel efficiency. With its robust construction and advanced technology, this engine ensures optimal power output and long-lasting performance.
Rated Power Output: Our 30kVA generator provides a steady power output of 30 kilovolt-amperes (kVA), making it suitable for a wide range of applications, from small businesses to residential backup power.
Efficient and Fuel-Saving: The Isuzu JE493ZDB-04 engine is designed for excellent fuel efficiency, allowing you to save on operational costs without compromising performance. This makes our 30kVA generator a cost-effective solution for your power needs.
Compact and Portable: With its compact design, our 30kVA generator offers easy installation and transportation. It is ideal for use in various settings, such as construction sites, events, and remote locations.
Advanced Alternator: The generator is equipped with a high-quality alternator that ensures stable power generation and precise voltage regulation. This guarantees the safe operation of your sensitive electronic equipment.
Digital Control Panel: The generator comes with a user-friendly digital control panel, allowing you to monitor key parameters, perform diagnostics, and easily adjust settings as needed. This enhances convenience and control over the power supply.
Safety and Protection Features: Our 30kVA generator incorporates essential safety features, including automatic shutdown in case of low oil pressure or high engine temperature. This protects the generator and your connected equipment from potential damage.
Low Noise Emissions: Engineered with noise-reduction technology, our generator operates quietly, minimizing disturbances in residential or noise-sensitive areas.
Generator Set Specification | ||
Model | A-I33 | |
Max. Power | kVA | 33 |
kW | 26 | |
Rate Power | kVA | 30 |
kW | 24 | |
Frequency | Hz | 50 |
Rate Voltage | V | 400/230 |
Rate Current | A | 43.3 |
Fuel Tank Capacity | L | 60 |
Dimension For Open-type Genset | mm | 1560 X 680 X 1350 |
Weight For Open-type Genset | kg | 630 |
Dimension For Soundproof Genset | mm | 1950 X 900 X 1200 |
Weight For Soundproof Generator | kg | 960 |
Noise Level for Soundproof Generator at 7M | dBA | 70 |
Battery | Two of 80Amps Free Maintenance Battery |
Engine Specification | ||
Engine Manufacturer | JMC Isuzu | |
Engine Brand | Isuzu | |
Engine Model | JE493ZDB-04 | |
No. of Cylinder | 4 Cylinder in line | |
Aspiration | Turbocharged | |
Governor | Electric | |
Engine Max. Output Power | kW | 31 |
Displacement | L | 2.77 |
Compression Ratio | 18.2 : 1 | |
Starting Voltage | V | 12 |
Bore | mm | 93 |
Stroke | mm | 102 |
Lubrication Oil Capacity | L | 5.6 |
Intake Air Flow | L/S | N.A |
Fuel Consumption at 100% Load | L/H | 5.6 |
Why Choose Hosem Power?
1. Hosem Power engaged in the generator area for 15 years, we have rich experience in R&D and manufacturing generator sets.
2. Every generator will be tested strictly before shipment, including:
3. production is submitted to ISO8528 and CE certification, and quality is certified by ISO9001 Management System to guarantee high-quality products and service.
FAQ
Q: What's your warranty?
A: All our products we offer one year warranty or 1000 hours which comes first.
Q: What's your delivery time?
A: Standard product 20 days - 35 days. Customized product 40 days.
Q: Can we add our logo to products?
A: Yes, there are several ways to do this. We can put the label of your logo on the products or make the silk print of your logo on the products. It is free.
Q: Can we customize the product?
A: We have a very experienced technical team, we can customize any product according to your requirements, such as synchronization system, wet exhaust system, ultra-silent system
Q: What certifications are for your gen sets?
A: ISO9001-2008, ISO14001-2004, CE, SASO, SONCAP, RETIE, etc.
Model | Standby Power | Prime Power | Engine Model | Dimension | Weight | Datasheet | ||
kVA | kW | kVA | kW | LXWXH(MM) | KG | |||
A-I17 | 15 | 12 | 17 | 13 | 4JA1-D1 | 2008x900x1130 | 570 | Download |
A-I22 | 20 | 16 | 22 | 18 | 4JA1-F1 | 2008x900x1130 | 580 | Download |
A-I28 | 25 | 20 | 28 | 22 | 4JA1-Z1 | 2008x900x1130 | 630 | Download |
A-I28 | 25 | 20 | 28 | 22 | 4JB1 | 2188x900x1280 | 630 | Download |
A-I33 | 30 | 24 | 33 | 26 | 4JB1T | 2188x900x1280 | 640 | Download |
A-I41 | 38 | 30 | 41 | 33 | 4JB1TA | 2188x900x1280 | 640 | Download |
A-I41 | 38 | 30 | 41 | 33 | 4JB1TA | 2188x900x1280 | 655 | Download |
A-I55 | 50 | 40 | 55 | 44 | 4JB1T-S | 2188x900x1280 | 675 | Download |
A-I55 | 50 | 40 | 55 | 44 | 4BD1-Z | 2388x1000x1450 | 700 | Download |
A-I69 | 63 | 50 | 69 | 55 | 4BG1-Z | 2388x1000x1450 | 860 | Download |
A-I110 | 100 | 80 | 110 | 88 | 6BG1-Z1 | 3288x1130x1850 | 1250 | Download |
A-I125 | 113 | 90 | 125 | 100 | 6BG1-ZL1 | 3288x1130x1850 | 1340 | Download |
A-I22 | 22 | 18 | 20 | 16 | JE493DB-04 | 2188x900x1280 | 620 | Download |
A-I28 | 28 | 22 | 25 | 20 | JE493DB-02 | 2188x900x1280 | 640 | Download |
A-I33 | 33 | 26 | 30 | 24 | JE493ZDB-04 | 2188x900x1280 | 670 | Download |
A-I44 | 44 | 35 | 40 | 32 | JE493ZLDB-02 | 2188x900x1280 | 690 | Download |
Model | Standby Power | Prime Power | Engine Model | Dimension (Silent Type) | Weight | Datasheet | ||
kVA | kVA | LXWXH(MM) | KG | |||||
A-I22H | 22 | 18 | 20 | 16 | 4JA1-D1 | 2008x900x1130 | 580 | Download |
A-I28H | 28 | 22 | 25 | 20 | 4JA1-F1 | 2008x900x1130 | 590 | Download |
A-I30H | 30 | 24 | 28 | 22 | 4JB1 | 2008x900x1130 | 630 | Download |
A-I33H | 33 | 26 | 30 | 24 | 4JA1-Z1 | 2008x900x1130 | 645 | Download |
A-I38H | 38 | 30 | 33 | 26 | 4JB1T | 2188x900x1280 | 675 | Download |
A-I48H | 48 | 39 | 44 | 35 | 4JB1TA | 2188x900x1280 | 690 | Download |
A-I62H | 62 | 50 | 56 | 45 | 4JB1T-S | 2188x900x1280 | 780 | Download |
A-I62H | 62 | 50 | 56 | 45 | 4BD1-Z | 2388x1000x1450 | 780 | Download |
A-I76H | 76 | 61 | 69 | 55 | 4BG1-Z | 2388x1000x1450 | 880 | Download |
A-I128H | 128 | 102 | 116 | 93 | 6BG1-Z1 | 3288x1130x1850 | 1200 | Download |
A-I138H | 138 | 110 | 125 | 100 | 6BG1-ZL1 | 3288x1130x1850 | 1360 | Download |
A-I28H | 28 | 22 | 25 | 20 | JE493DB-03 | 2188x900x1280 | 630 | Download |
A-I33H | 33 | 26 | 30 | 24 | JE493DB-01 | 2188x900x1280 | 655 | Download |
A-I41H | 41 | 33 | 38 | 30 | JE493ZDB-03 | 2188x900x1280 | 660 | Download |
A-I55H | 55 | 44 | 50 | 40 | JE493ZLDB-01 | 2188x900x1280 | 700 | Download |
ATS
ATS cabinet is mainly applied to the automatic switch between prime and emergency power, composing an automatic emergency power supply system together with diesel generating sets. It will monitor prime power, When it is cut off, it can automatically switch loads such as emergency illumination, security power and fire fighting equipment to generating sets. Auto start, auto transfer, auto protection, auto power supply
Standard configuration:
Brand: ABB, Schneider, Socome, Suyang, AISIKAI
PARALLEL DISTRIBUTION CABINET
Parallel distribution cabinet is designed for the parallel running of main power diesel generator sets. The system can operate automatically or be controlled manually.
The system has the functions of automatic frequency detection, synchronizing detection and switch-on.
It is convenient to expand the capacity to satisfy the need of increasing load.
It can be used together with multiple generating sets (32 parallel generating sets max.) to control multiple diesel generating sets for automatic synchronization.
It offers stable frequency and voltage and can bear large-capacity load impact, achieving reliable supply, centralized management and more flexible power allocation.
Load Bank
The purpose of most land banks is used to test of the emergency generator sets, verifying all genset components are in optimal working condition under different loads. Another purpose is working combined with the generator set, to take the load of the generator set is always above 30%
Advantages of Load Bank
Three types of load banks are usually used to genset.
