Cummins generators are world well-known brand for their exceptional reliability and durability, as well as with a strong global presence, Cummins provides comprehensive support to its customers, including installation, maintenance, and technical assistance over the world.
Special the 60kW, 80kW and 100kW cummins generator is a optimal choice for residential and commercial use to large industrial systems capable of powering entire facilities
If you want learn moe about Chinese made cummins, pls refer to article below
The Best Generator Brands in China: All You Need to Know
Cummins Diesel Generator Manual Download
Model | Standby Power | Prime Power | Engine Model | Dimension (Open Type) | Weight | Datasheet | ||
kVA | kW | kVA | kW | LXWXH(MM) | KG | |||
A-C22-1 | 22 | 18 | 20 | 16 | 4B3.9-G1 | 1770x830x1050 | 880 | Download |
A-C22-2 | 22 | 18 | 20 | 16 | 4B3.9-G2 | 1770x830x1050 | 880 | Download |
A-C28-1 | 28 | 22 | 25 | 20 | 4B3.9-G1 | 1770x830x1050 | 920 | Download |
A-C28-2 | 28 | 22 | 25 | 20 | 4B3.9-G2 | 1770x830x1050 | 920 | Download |
A-C44-1 | 44 | 35 | 40 | 32 | 4BT3.9-G1 | 1770x830x1050 | 950 | Download |
A-C44-2 | 44 | 35 | 40 | 32 | 4BT3.9-G2 | 1770x830x1050 | 950 | Download |
A-C55 | 50 | 40 | 55 | 50 | 4BT3.9-G2 | 1770x830x1050 | 980 | Download |
A-C60 | 60 | 50 | 55 | 45 | 4BTA3.9-G2 | 1820x830x1050 | 980 | Download |
A-C72 | 72 | 57 | 65 | 52 | 4BTA3.9-G2 | 1820x830x1050 | 1050 | Download |
A-C88 | 88 | 70 | 80 | 63 | 4BTA3.9-G11 | 1820x830x1050 | 1080 | Download |
A-C100 | 100 | 77 | 90 | 70 | QSB3.9-G3 | 1820x830x1050 | 1080 | Download |
A-C110-1 | 110 | 88 | 100 | 80 | 6BT5.9-G1 | 2180x830x1200 | 1200 | Download |
A-C110-2 | 110 | 88 | 100 | 80 | 6BT5.9-G2 | 2180x830x1200 | 1250 | Download |
A-C121 | 121 | 96 | 110 | 87 | 6BT5.9-G2 | 2180x830x1200 | 1300 | Download |
A-C138 | 138 | 110 | 125 | 100 | 6BTA5.9-G2 | 2300x830x1450 | 1330 | Download |
A-C150-1 | 150 | 119 | 136 | 109 | QSB5.9-G3 | 2300x830x1450 | 1350 | Download |
A-C150-2 | 150 | 119 | 136 | 109 | 6BTAA5.9-G2 | 2300x830x1450 | 1350 | Download |
A-C175 | 175 | 140 | 160 | 127 | 6BTAA5.9-G12 | 2300x830x1450 | 1400 | Download |
A-C203-1 | 203 | 163 | 185 | 148 | 6CTA8.3-G1 | 2654x1156x1595 | 1500 | Download |
A-C203-2 | 203 | 163 | 185 | 148 | 6CTA8.3-G2 | 2654x1156x1595 | 1500 | Download |
A-C210 | 210 | 167 | 190 | 152 | QSB6.7-G4 | 2654x1156x1595 | 1650 | Download |
A-C228 | 228 | 182 | 207 | 166 | 6CTAA8.3-G2 | 2654x1156x1595 | 1600 | Download |
A-C275-1 | 275 | 220 | 250 | 200 | MTA11-G2A | 3315x1100x1650 | 2950 | Download |
A-C275-2 | 275 | 220 | 250 | 200 | MTA11-G2 | 3315x1100x1650 | 2950 | Download |
A-C275-3 | 275 | 220 | 250 | 200 | NTA855-G1 | 3315x1100x1650 | 2950 | Download |
A-C275-4 | 275 | 220 | 250 | 200 | 6LTAA8.9-G2 | 2654x1156x1595 | 1750 | Download |
A-C286 | 286 | 229 | 260 | 208 | 6LTAA8.9-G3 | 2654x1156x1595 | 1800 | Download |
A-C290 | 290 | 232 | 260 | 208 | QSL8.9-G4 | 2654x1156x1595 | 1900 | Download |
A-C300 | 300 | 240 | 275 | 220 | NTA855-G1A | 3315x1100x1650 | 2950 | Download |
A-C312 | 312 | 250 | 284 | 227 | 6LTAA9.5-G3 | 3000x1115x1880 | 2940 | Download |
A-C344-1 | 344 | 275 | 313 | 250 | MTAA11-G3 | 3315x1100x1650 | 2950 | Download |
A-C350 | 350 | 280 | 313 | 250 | NTA855-G1B | 3315x1100x1650 | 2950 | Download |
A-C344-3 | 344 | 275 | 313 | 250 | NTA855-G2 | 3315x1100x1650 | 2950 | Download |
A-C344-4 | 344 | 275 | 313 | 250 | 6LTAA9.5-G1 | 3000x1115x1880 | 3050 | Download |
A-C378 | 378 | 302 | 343 | 275 | NTA855-G2A | 3315x1100x1650 | 3150 | Download |
A-C385 | 385 | 308 | 350 | 280 | NTA855-G4 | 3315x1100x1650 | 3150 | Download |
A-C408 | 408 | 326 | 370 | 296 | QSZ13-G6 | 3000x1115x1880 | 3200 | Download |
A-C413-1 | 413 | 330 | 375 | 300 | NTAA855-G7 | 3315x1100x1650 | 3250 | Download |
A-C413-2 | 413 | 330 | 375 | 300 | KTA19-G2 | 3580x1450x 2160 | 3250 | Download |
A-C424-1 | 424 | 340 | 385 | 310 | 6ZTAA13-G3 | 3300x970x1650 | 3450 | Download |
A-C424-2 | 424 | 340 | 385 | 310 | 6ZTAA13-G3 | 3300x970x1650 | 3450 | Download |
A-C450 | 450 | 360 | N/A | N/A | NTAA855-G7A | 3315x1100x1650 | 3500 | Download |
A-C456 | 456 | 365 | 415 | 332 | QSZ13-G7 | 3000x1115x1880 | 3500 | Download |
A-C484 | 484 | 387 | 440 | 352 | 6ZTAA13-G2 | 3300x970x1650 | 4000 | Download |
A-C495-1 | 495 | 396 | 450 | 360 | KTA19-G3 | 3580x1450x 2160 | 4000 | Download |
A-C495-2 | 495 | 396 | 450 | 360 | 6ZTAA13-G4 | 3300x970x1650 | 4000 | Download |
A-C495-3 | 495 | 396 | 450 | 360 | QSZ13-G2 | 3000x1115x1880 | 4000 | Download |
A-C511 | 511 | 409 | 465 | 372 | QSZ13-G5 | 3000x1115x1880 | 4000 | Download |
A-C550-1 | 550 | 440 | 500 | 400 | KTA19-G3A | 3580x1450x 2160 | 4200 | Download |
A-C550-2 | 550 | 440 | 500 | 400 | KTA19-G4 | 3580x1450x 2160 | 4200 | Download |
A-C560 | 560 | 448 | 510 | 408 | QSZ13-G3 | 3000x1115x1880 | 4000 | Download |
A-C575 | 575 | 462 | 525 | 420 | KTAA19-G5 | 3580x1450x 2160 | 4200 | Download |
A-C633 | 633 | 506 | 575 | 460 | KTAA19-G6 | 3580x1450x 2160 | 4800 | Download |
A-C650 | 650 | 520 | N/A | N/A | KTA19-G8 | 3580x1450x 2160 | 4800 | Download |
A-C688-1 | 688 | 550 | N/A | N/A | KTAA19-G6A | 3580x1450x 2160 | 4800 | Download |
A-C688-2 | 687 | 550 | 625 | 500 | KT38-G | 4350x1850x2400 | 7350 | Download |
A-C784 | 784 | 627 | 713 | 570 | KTA38-G1 | 4350x1850x2400 | 7650 | Download |
A-C800 | 800 | 640 | 725 | 580 | KT38-GA | 4350x1850x2400 | 7850 | Download |
A-C825 | 825 | 660 | 750 | 600 | KTA38-G2 | 4350x1850x2400 | 7850 | Download |
A-C880 | 880 | 704 | 800 | 640 | KTA38-G2B | 4350x1850x2400 | 7850 | Download |
A-C1000 | 1000 | 800 | 910 | 728 | KTA38-G2A | 4350x1850x2400 | 7850 | Download |
A-C1100 | 1100 | 880 | 1000 | 800 | KTA38-G5 | 4350x1850x2400 | 7850 | Download |
A-C1250 | 1250 | 1000 | N/A | N/A | KTA38-G9 | 4350x1850x2400 | 8150 | Download |
A-C1375 | 1375 | 1100 | 1250 | 1000 | KTA50-G3 | 5200 X 1920 X 2379 | 10800 | Download |
A-C1513 | 1513 | 1210 | 1375 | 1100 | KTA50-G8 | 5200 X 1920 X 2379 | 10800 | Download |
A-C1650 | 1650 | 1320 | 1500 | 1200 | KTA50-GS8 | 5200 X 1920 X 2379 | 10800 | Download |
Model | Standby Power | Prime Power | Engine Model | Dimension (Open Type) | Weight | Datasheet | ||
kVA | kW | kVA | kW | LXWXH(MM) | KG | |||
A-C25H | 25 | 20 | 23 | 18 | 4B3.9-G2 | 1770x830x1050 | 880 | Download |
A-C38H | 38 | 30 | 34 | 27 | 4BT3.9-G2 | 1770x830x1050 | 880 | Download |
A-C50H | 50 | 40 | 45 | 36 | 4BT3.9-G2 | 1770x830x1050 | 920 | Download |
A-C60H | 60 | 48 | 55 | 44 | 4BTA3.9-G2 | 1770x830x1050 | 920 | Download |
A-C75H | 75 | 60 | 68 | 55 | 4BTA3.9-G2 | 1770x830x1050 | 950 | Download |
A-C100H | 100 | 80 | 90 | 72 | 4BTA3.9-G11 | 1770x830x1050 | 1050 | Download |
A-C125H | 125 | 100 | 114 | 91 | 6BT5.9-G2 | 2180x830x1200 | 1200 | Download |
A-C143H | 143 | 115 | 130 | 104 | 6BTA5.9-G2 | 2180x830x1200 | 1250 | Download |
A-C165H | 165 | 132 | 150 | 120 | 6BTAA5.9-G2 | 2180x830x1200 | 1300 | Download |
A-C188H | 188 | 150 | 170 | 136 | 6BTAA5.9-G12 | 2180x830x1200 | 1350 | Download |
A-C206H | 206 | 165 | 188 | 150 | 6CTA8.3-G2 | 2654x1156x1595 | 1500 | Download |
A-C238H | 238 | 190 | 216 | 173 | 6CTAA8.3-G2 | 2654x1156x1595 | 1550 | Download |
A-C275H | 275 | 220 | N/A | N/A | NT855-GA | 3315x1100x1650 | 2500 | Download |
A-C290H | 290 | 233 | 265 | 212 | 6LTAA8.9-G2 | 2654x1156x1595 | 1750 | Download |
A-C344H | 344 | 275 | 313 | 250 | NTA855-G1 | 3315x1100x1650 | 2450 | Download |
A-C316H | 316 | 253 | 288 | 230 | 6LTAA8.9-G3 | 2654x1156x1595 | 1750 | Download |
A-C330H | 330 | 264 | 300 | 240 | 6LTAA9.5-G3 | 3000x1115x1880 | 1850 | Download |
A-C375H | 375 | 300 | 344 | 275 | NTA855-G1B | 3315x1100x1650 | 2500 | Download |
A-C375H-1 | 375 | 300 | 344 | 275 | NTA855-G2 | 3315x1100x1650 | 2550 | Download |
A-C347H | 347 | 277 | 315 | 252 | 6LTAA9.5-G1 | 3000x1115x1880 | 3650 | Download |
A-C438H | 438 | 350 | 398 | 318 | NTA855-G3 | 3315x1100x1650 | 2650 | Download |
A-C424H | 424 | 339 | 386 | 309 | 6ZTAA13-G3 | 3300x970x1650 | 3600 | Download |
A-C445H | 445 | 356 | 405 | 324 | QSZ13-G6 | 3000x1115x1880 | 4000 | Download |
A-C481H | 481 | 385 | 438 | 350 | KTA19-G2 | 3580x1450x2160 | 4000 | Download |
A-C487H | 487 | 389 | 443 | 354 | 6ZTAA13-G2 | 3300x970x1650 | 3800 | Download |
A-C500H | 500 | 400 | 455 | 364 | 6ZTAA13-G4 | 3300x970x1650 | 3800 | Download |
A-C500H-1 | 500 | 400 | 455 | 364 | QSZ13-G2 | 3000x1115x1880 | 4000 | Download |
A-C511H | 511 | 409 | 465 | 372 | QSZ13-G7 | 3000x1115x1880 | 4000 | Download |
A-C564H | 564 | 451 | 512 | 410 | KTA19-G3 | 3580x1450x 2160 | 4200 | Download |
A-C563H | 563 | 450 | 511 | 409 | QSZ13-G5 | 3000x1115x1880 | 4000 | Download |
A-C563H-1 | 563 | 450 | 511 | 409 | QSZ13-G3 | 3000x1115x1880 | 4000 | Download |
A-C618H | 618 | 495 | 562 | 450 | KTA19-G3A | 3580x1450x2160 | 4200 | Download |
A-C618H-1 | 618 | 495 | 562 | 450 | KTA19-G4 | 3580x1450x2160 | 4800 | Download |
A-C646H | 646 | 517 | 587 | 470 | KTAA19-G5 | 3580x1450x2160 | 4800 | Download |
A-C750H | 750 | 600 | N/A | N/A | KTAA19-G6A | 3580x1450x2160 | 4800 | Download |
A-C850H | 850 | 680 | 775 | 620 | KT38-G | 4350x1850x2400 | 7650 | Download |
A-C963H | 963 | 770 | 875 | 700 | KTA38-G1 | 4350x1850x2400 | 7650 | Download |
A-C997H | 997 | 798 | 906 | 725 | KTA38-G2 | 4350x1850x2400 | 7650 | Download |
A-C1031H | 1031 | 825 | 938 | 750 | KTA38-G2B | 4350x1850x2400 | 7850 | Download |
A-C1100H | 1100 | 880 | 1000 | 800 | KTA38-G2A | 4350x1850x2400 | 7850 | Download |
A-C1238H | 1238 | 990 | 1125 | 900 | KTA38-G4 | 4350x1850x2400 | 7850 | Download |
A-C1525H | 1525 | 1220 | N/A | N/A | KTA38-G9 | 4350x1850x2400 | 8150 | Download |
A-C1513H | 1513 | 1210 | 1375 | 1100 | KTA50-G3 | 5200 X 1920 X 2379 | 10800 | Download |
A-C1733H | 1733 | 1386 | 1575 | 1260 | KTA50-G9 | 5200 X 1920 X 2379 | 10800 | Download |
ATS
ATS cabinet is mainly applied to the automatic switch between prime and emergency power, composing an automatic emergency power supply system together with diesel generating sets. It will monitor prime power, When it is cut off, it can automatically switch loads such as emergency illumination, security power and fire fighting equipment to generating sets. Auto start, auto transfer, auto protection, auto power supply
Standard configuration:
Brand: ABB, Schneider, Socome, Suyang, AISIKAI
PARALLEL DISTRIBUTION CABINET
Parallel distribution cabinet is designed for the parallel running of main power diesel generator sets. The system can operate automatically or be controlled manually.
The system has the functions of automatic frequency detection, synchronizing detection and switch-on.
It is convenient to expand the capacity to satisfy the need of increasing load.
It can be used together with multiple generating sets (32 parallel generating sets max.) to control multiple diesel generating sets for automatic synchronization.
It offers stable frequency and voltage and can bear large-capacity load impact, achieving reliable supply, centralized management and more flexible power allocation.
Load Bank
The purpose of most land banks is used to test of the emergency generator sets, verifying all genset components are in optimal working condition under different loads. Another purpose is working combined with the generator set, to take the load of the generator set is always above 30%
Advantages of Load Bank
Three types of load banks are usually used to genset.
